AMPIRE active DAB+ antenna splitter

If you want to equip a car radio with DAB+ and still have a telescopic or passive rod antenna without a built-in amplifier, use a DAB+ antenna splitter or antenna splitter. This allows you to use this antenna for both FM and DAB+ and avoids the need to install additional DAB+ antennas.

FEATURES
- Active DAB+ antenna splitter
- Plug & Play - easy installation
- Low-noise amplifier
- Gold-plated SMB right-angle connector
- No need to install additional DAB antennas
- For FM antennas from 30 to 100 cm in length

TECHNICAL DATA
- Adapter length: approximately 34 cm
- 1x gold-plated SMB right-angle connector
- 1x DIN antenna connector 150 Ohm
- 1x DIN 150 Ohm antenna coupling
- Supply voltage: 12 V
- Power consumption: 6 mA
- Noise factor: < 2 dB

- Connect the blue cable to the remote output of the car radio.

IMPORTANT NOTES
- Not suitable for antennas with phantom power or disc antennas
- The antenna power must be switched off at the DAB device
