AMPIRE Dual Voice Coil Subwoofer 6.5"

These high-quality dual voice coil (DVC) subwoofers from the BOLD series are the key to clean and powerful sound reproduction in the lowest frequency range, even at very high volumes. Naturally, they are optimally designed to be combined with other AMPIRE component speakers – guaranteeing a clean and harmonious soundstage across all frequency ranges, even at high sound pressure levels. The cone is made of a very lightweight and highly durable polycarbonate composite, and the specially developed butyl rubber surround ensures an extremely linear frequency response. The significantly oversized voice coil operates very efficiently and is optimally cooled in the unconventional magnetic drive. Despite its compact size, this subwoofer can also reproduce frequencies below 50 Hz with exceptional clarity. The ventilation opening at the rear of the magnet has been designed to be as large as possible and rounded, effectively minimizing flow noise and optimizing the necessary pressure equalization.

QUOTES FROM CAR & HIFI TEST REPORT 1/2013
Test result: "exceptional"
"...the quadruple double acoustic coil in 38mm format is an announcement..."
"It works perfectly in bass reflex speakers, where it's good for a lower frequency limit below 45 Hz - you have to let it melt in your mouth."
"He plays equally well with deep passes and with very clear, sharp ones."
"A true audiophile woofer that ages many highly appreciated bass frequencies."
"The BOLD6 is a small woofer with very big ambitions. It delivers what many mini-woofers promise - and for very little money."

TECHNICAL SPECIFICATIONS
- Dual voice coil subwoofer chassis
- Nominal diameter: 165 mm
- Impedance: 4 + 4 ohms
- Steel sheet basket
- 1.5"/38 mm double spool
- Polycarbonate membrane
- Ventilated centering spider
- 8 mm X-max.
- Ultra low bass technology
- Load capacity PE 125/250 watts

Case (closed)
- 10 liters with chassis, F3 66 Hz, SPL 110 dB at 70 Hz

Optimal enclosure for sound (bass reflex):
- 11.4 liters with frame and hose displacement
- 5 cm tube with a length of 20 cm
- F3 42 Hz, SPL 117 dB at 56 Hz

TERM-PRO CASE CALCULATION INCLUDED
When you purchase this subwoofer, you will receive a free, custom subwoofer calculation for your specific car. Please send the exact dimensions you require and any other relevant system information to support@ampire.de. Remember to include the invoice number you used to purchase the subwoofer from us.

TS PARAMETERS (acoustic coils connected in parallel at 2 ohms):
- Fs: 40.28 Hz.
- VAS: 10.899 liters
- Qty: 0.449
- Qes: 0.488
- Qms: 5.602
- Re: 3.3 + 3.3 ohms
- Z: 4 + 4 ohms
- SPL: 83.5 dB
- Mmd. : 31.83 gr.
- Xmax: 8 mm
- Sd: 126.7 cm²
- Vd: 101.4 cm³
- D: 127.0 mm
